| Resolution (H x V) |
1920 x 1080 Pixels |
| Image Sensor |
1/2.7" CMOS |
| Scanning System |
Progressive Scan |
| IR cut filter |
Colour (Day), Monochrome (Night), Auto, Schedule |
| Shutter Time |
1/30(1/25)s - 1/8.000s |
| Lens |
4mm |
| Angle of View |
- 94°(H)
- 45.2°(V)
- 100.6°(D)
|
| IR Radiant Distance |
16M |
| Infrared LED Angle |
30° |
| Peak wavelength |
850nm, High efficiency array |
| Video Compression |
H.264, Motion JPEG |
| Frame
Rate |
- H.264 : up to 15 FPS @ 1920 x 1080
- Motion JPEG : up to 15 FPS @ 1920 x 1080
|
| Video Streaming |
RTP/HTTP, RTP/TCP, RTP/UDP, Multicast |
| Video Bitrate |
128Kbps – 5Mbps |
| Sense Up |
Off / 1 Frame / 2 Frames / 3 Frames / 7 Frames |
| Sense Up+ |
Yes |
| Auto Gain Control |
36 dB Variable Gain |
| 3D Noise Reduction |
Off / 1 – 32 Selectable |
| 2D WDR |
Off / x2 / x3 / x4 |
| Privacy Masking |
Off / On (4 independent areas) |
| ePTZ & Digital Zoom |
Yes |
| Alarm Function |
- Image upload over FTP and E-mail by motion detection
|
| Network Interface |
10Mbps / 100Mbps Base-T, RJ-45 |
| Dimensions |
Ø120 x 102mm |
| Weight |
450g |
| Power Supply |
DC12V-7.5W / PoE-8.5W |
