| Resolution (H x V) |
1920 x 1080 Pixels |
| Image Sensor |
1/2.86" CMOS |
| Scanning System |
Progressive Scan |
| IR cut filter |
Colour (Day), Monochrome (Night), Auto, Schedule |
| Shutter Time |
1/30(1/25)s - 1/30.000s |
| Lens |
2.8-12mm |
| Angle of View |
- 91.2° - 25.5°(H)
- 59.4° - 22.4°(V)
- 99° - 37.3°(D)
|
| IR Radiant Distance |
45M |
| Infrared LED Angle |
30° |
| Peak wavelength |
850nm |
| Video Compression |
H.264, Motion JPEG |
| Frame
Rate |
- H.264 : up to 60 FPS @ 1920 x 1080
- MJPEG : up to 30 FPS @ 720 x 480
|
| Video Streaming |
RTP/HTTP, RTP/TCP, RTP/UDP, Multicast |
| Video Bitrate |
128Kbps - 12Mbps |
| Sense Up |
Off / 1 Frame / 2 Frames / |
| Sense Up+ |
Yes |
| Auto Gain Control |
54 dB Variable Gain |
| 3D Noise Reduction |
Off / 1 – 32 Selectable |
| 2D WDR |
Off / Auto / x2 / x3 / x4 |
| Privacy Masking |
Off / On (4 independent areas) |
| ePTZ & Digital Zoom |
Yes, ROI is supported |
| Alarm Function |
- Tampering / Audio / Motion / Alarm detection
- Image upload over FTP and E-mail by tampering / Audio / Motion detection
|
| Network Interface |
10Mbps / 100 / 1000Mbps Base-T, RJ-45 |
| Audio |
2-way audio , G.711 / PCM |
| SD Card |
Support Micro SD/SDHC card |
| IP Rating |
IP66 |
| Dimensions(W x H x D)mm |
121.5 x 109 x 231mm, Bracket : 160mm (L) |
| Weight |
1700g |
| Power Supply |
AC24V-15W / PoE-16.5W |
