| Resolution (H x V) |
1920 x 1080 Pixels |
| Image Sensor |
1/2.86" CMOS |
| Scanning System |
Progressive Scan |
| Shutter Time |
1/30(1/25)s - 1/30.000s |
| Lens |
2.8mm |
| Angle of View |
|
| Video Compression |
H.264, Motion JPEG |
| Frame
Rate |
- H.264 : up to 60 FPS @ 1920 x 1080
- Motion JPEG : up to 30 FPS @ 720 x 480
|
| Video Streaming |
RTP/HTTP, RTP/TCP, RTP/UDP, Multicast |
| Video Bitrate |
128Kbps – 12Mbps |
| Sense Up |
Off / 1 Frame / 2 Frames |
| Sense Up+ |
Yes |
| Auto Gain Control |
54 dB Variable Gain |
| 3D Noise Reduction |
Off / 1 – 32 Selectable |
| 2D WDR |
Off / Auto / x2 / x3 / x4 |
| Privacy Masking |
Off / On (4 independent areas) |
| ePTZ & Digital Zoom |
Yes, ROI is supported |
| Alarm Function |
- Tampering / Audio / Motion detection
|
| Network Interface |
10Mbps / 100 / 1000Mbps Base-T, RJ-45 |
| Audio |
1-way Audio, G.711 / PCM |
| SD Card (recording) |
Support Micro SD/SDHC/SDXC card |
| Dimensions |
Ø105 x 39mm |
| Weight |
310g |
| Power Supply |
DC12V-6W / PoE-6.8W |
|
