| Resolution (H x V pixels) |
1920 x 1080 Pixels |
| Image Sensor |
1/3" CMOS |
| Scanning System |
Progressive Scan |
| IR cut filter |
Colour (Day), Monochrome (Night), Auto |
| Shutter Time |
Off / Auto / Manual, 1/1(1/0.75)s - 1/30.000s |
| Zoom Ratio |
30X Optical Zoom |
| Lens/Focal length |
4.4mm (Wide) - 132mm (Tele) |
| Angle of View |
- 63° - 2.3°(H)
- 37.3° - 1.3°(V)
|
| IR Radiant Distance |
150m |
| Peak wavelength |
850nm |
| Video Compression |
H.264, Motion JPEG |
| Frame
Rate |
- H.264 : up to 30 FPS @ 1920 x 1080
- MJPEG : up to 15 FPS @ 1920 x 1080
|
| Video Streaming |
RTP/HTTP, RTP/TCP, RTP/UDP, Multicast |
| Video Bitrate |
128Kbps – 5Mbps |
| Auto Gain Control |
0 ~ 45 dB(16 steps) |
| Sense Up+ |
Off / Auto / 1 / 2 / 3 |
| 3D Noise Reduction |
Off / On (Level: 1~3) |
| 2D WDR |
Off / On |
| Privacy Masking |
Off / On (16 zones) |
| ePTZ & Digital Zoom |
12X |
| Alarm Function |
- Image upload over FTP and E-mail by alarm / Motion Detection
|
| Network Interface |
10Mbps / 100Mbps, RJ-45 |
| Audio |
2-way Audio, G.711 / PCM |
| SD Card/ SD card recording |
Support Micro SD/SDHC card |
| IP Rating |
IP66 |
| Dimensions |
Ø228 x 347mm |
| Weight |
4700g |
| Power Supply |
AC24V-67W |
